FIRETEX® M90/02
High-Performance Fire and Corrosion Protection
An Epoxy Intumescent Coating Providing Durable Passive Hydrocarbon Jet Fire Protection with FIRETEX® M90/02
FIRETEX M90/02 provides up to four hours of fire protection while providing a corrosion-resistant protective coating for the design life of the asset. With low spray applied density, reduced film build requirements, and high-performance properties, FIRETEX M90/02 is highly recommended for LNG plants, refineries, chemical processing plants, and offshore structures against hydrocarbon and jet fire. It also provides fire protection and cryogenic spill protection when used in conjunction with FIRETEX M89/02.
FIRETEX M90/02 has a low density and low jet fire thickness requirements making it ideal for offshore platforms for durable fire and corrosion protection. FIRETEX M90/02 is fully tested and certified to global industry standards to effectively mitigate damaging impacts caused from fire and explosion.
FIRETEX® M90/02 Fire Protection Coating offers:
- Anticorrosive coating suitable for harsh environments
- UL 1709 certified for up to four hours of protection
- BLEVE
- Cryogenic spill protection
- Global Fire testing: Pool fire (BS476-20&21, ISO834-3) Jet fire (ISO22899-1)
- Blast resistance
Why FIRETEX M90/02?
Passive Fire Protection (PFP) – 100% Solids Epoxy Intumescent Coating
- Certified for over three hours of jet fire protection and up to four hours of hydrocarbon pool fire protection
- Versatility of application - shop or onsite applied
- Fully tested and certified to global industry standards to effectively mitigate damaging impacts caused from fire and explosion
Want to know if the FIRETEX® M90/02 fire protection coating is right for your project?
Get in touch with our industry leading sales and tech teams. They can help determine the right advanced fireproofing coatings and offer comprehensive specification support for your project. Or scroll down to learn more.
Features & Benefits
FIRETEX M90/02 Epoxy Intumescent Coating is 100% solids and certified for over three hours of jet fire protection and up to four hours of hydrocarbon pool fire protection. It is a durable, anticorrosive high-performance intumescent coating that provides resistance to harsh environments within hydrocarbon processing plants and on offshore structures.
Application Time Savings
- Quick overcoating times
- Excellent sag resistance and a high-film build with minimal finishing requirements
- Excellent application properties: plural-component, single-leg RAM feed airless and hand trowel
Cost Effectiveness
- Low Jet fire thickness requirements
- Application versatility to be applied in shops, modular yards or onsite
- Low life cycle cost - minimal to no maintenance over the design life of the asset
Tested and Certified Protection
- UL 1709 certified up to four hours
- NFPA 58
- BAM Vessel Test
- Lloyds Register
- Det Norsk Veritas
- ISO 22899-1
- NORSOK M501 Rev 6
Extended Life of Assets
- Protects assets from both fire and corrosion through proven technology in both laboratory testing and years of exposure while in service
- Lowest lifecycle cost option
- Highly durable against chemical attack, mechanical damage, and weathering, providing a low to no maintenance protection system for assets
Recommended Uses
FIRETEX® M90/02 is a two-component epoxy coating used to enhance the fire resistance of structural materials by providing a layer of insulation, which is formed as a result of a chemical reaction initiated by fire. This insulation reduces the rate of heat transfer and extends the time period for which the structural material can resist the weakening effects of the heat. Typical uses for FIRETEX M90/02 include:
- Onshore facilities
- Offshore structures
- Refineries
- Chemical plants
- LNG terminals
- Columns, beams, and bracing
- Pipe racks
- Support structures: skirts, legs and saddles
- Vessels, tanks, spheres, and spheroids
- Marine docks
- Modular units
